Rotating disk reactor Reservoir stimulation Matrix acidizing Instruments

The Rotating disk reactor Reservoir stimulation Matrix acidizing Instruments permits reaction rate studies between various fluids and solid surfaces. The apparatus consists of a rock disk rotating at constant velocity in a hermetic chamber filled with reactive fluid. The amplitude of mass transfer and chemical reactions can be adjusted by varying the rotational speed and experimental temperature.

Bulk reactant concentration is measured at specified time intervals via atomic absorption spectrophotometry. The global reaction rate at a given angular velocity is computed from the change in reactant concentration over time. The experiment is then repeated at different angular velocities to obtain the reaction rate as a function of angular velocity. Additional experiments at different temperatures or different test fluid concentrations can also be performed to determine the complete rate law for the reaction system.

Maximum pressure :

• 5,000 psi

Maximum temperature :

• 250°C

Reaction vessel volume :

• 500 ml

Reservoir vessel volume :

• 500 ml

Sample disk diameter :

• 1.5" (38.4 mm)

Sample disk thickness :

• 1" (25.4 mm)

Disk rotational speed :

• 100 to 2,000 RPM

Material :

• Hastelloy

Power supply :

• 220 VAC, 50 Hz

Nitrogen pressure requirement :

• 2,000 psi

Air pressure requirement :

• 150 psi, dry

• Semi-automated instrument
• Rapid, accurate and reproducible data
• Acid-resistant construction materials
• Small test fluid volume requirement
