Scraped Surface Heat Exchanger Series Deluxe

A miniature-scale scraped surface heat exchanger with built-in control and flexibility. Graphic representation of process on touch screen control panel. Parameters include margarine, shortening and ice cream processes.

A lab-scale crystalliser with scraped surface heat exchangers mounted on stainless-steel frame supplied with large 15.4 inch HD touchscreen and PLC control system. Working platform accommodates one or two barrels and variable speed pinworker alongside hopper and connection ports. Miniature-scale technology enables developers to run small trials providing information for scale-up to larger plant.

• Heat exchanger barrel heat transfer area: 0.045m²
• Shaft/barrel volume ratio: 1 : 3.5
• Scraper blades: 4 PEEK scrapers on stainless steel shaft, 2 pairs with 180° separation
• Barrel length: 0.35m
• Barrel working pressure: 20 bar or 40 bar
• Pinworker number of pins on shaft: 36
• Pinworker number of pins on barrel: 36
• Barrel/pinworker drives: Variable speed AC motors, inverter controlled
• Speed range: 100-1400rpm
• Refrigeration system food grade refrigerant: -25°C capability (Coolflow LVF50)
• Feed pump: Progressive cavity pump
• Process throughput: Up to 0-20l/h independent of back pressure
• Particulate capability: up to 0.6mm
• Fibre handling capability: up to 25mm
• Air incorporation system: Air pump with fine filter and digital flow controller
