Semi automated polishing machine laboratory and Oilfield instruments

The apparatus is a single purpose apparatus specifically designed for small-scale polishing operations. The robust, simple to use system provides high quality polished chips and thin sections with the minimum capital investment. The disc speed can be varied from 10-600 rpm. Polishing is achieved by means of polishing cloths or magnetic polishing discs. A polishing head with four holders for the chip or thin section production is supplied. The former allows efficient, simultaneous polishing of up to 4 samples. Variable up to 200 gram weights apply a force to hold the sample’s position on the disc. Two sets of four specimen holders are supplied to suit either 30x45mm or 1 x 1.5 inch samples.

Variable speed :

• 10 to 600 RPM

Specimen size :

• 30x45mm or 1 x 1.5 inches

Plate diameter :

• 250 mm

Dimensions :

• 526 x 589 x 380 mm

Weight :

• 50 kg

Power supply :

• 220 VAC - 50/60 Hz

• Free vibration at low speeds
• Polishs chips or thin sections
• Easy access for rapid and effortless leaning
• Simultaneous polishing up to four samples
