Sieve Shaker (Size : 75/200)

Application :

• The Sieve Shaker (Size: 75/200) is suitable for sieving soft, fibrous, hard and brittle materials in the dry and wet state and is designed for analytical test sieves from 75 to 203 mm

Control & Operation :

• All sieving parameters are digitally pre-selected and can be stored and recalled. The vibration is controlled by a microprocessor.

Performance :

• Depending on the characteristic of the sample material to be sieved a sieving process can be done down to 20 °m.

Capacity & Usage :

• The optimum filling level for each test sieve depends on the sieve frame diameter (75/100/150/200/203) and in relation of the mesh size of the test sieve.

Ambient temperature :

• 5C - 40C

Atmospheric humidity :

• 85% RH

Dimensions (W × D × H) :

• 300 × 240 × 240 mm (670 mm with rods)

Fuses :

• 2 - T2A 250V

Max sieve diameter :

• 200 mm and 8" (203 mm)

Min sieve diameter :

• 75 mm

Noise emission (without milling balls) :

• 70 dB(A)

Power supply :

• 230V × 10% × 50/60 Hz

Rated power :

• 400 W

Timer :

• 00 sec - 99 min, display of sieving time in minutes

Vibrational frequency regulation :

• Digital, from 3 to 30 Hz

Weight :

• 28 kg

Recommended Quantity :

Basis :

• Recommended maximum quantities of sieving material based on 1 kg = 1 dm°

Nominal Sieve Openings (mm) :

• Sieving product quantity (dm) (valid for sieves with 200 mm diameter)

8.00 mm :

• 0.500 dm°

3.15 mm :

• 0.300 dm

1.00 mm :

• 0.140 dm

0.50 mm :

• 0.100 dm

0.20 mm :

• 0.060 dm°

0.63 mm :

• 0.035 dm

0.020 mm :

• 0.020 dm
