The Silent Air Compressor Unitto supply compressed air to unit that includes pneumatic circuits.
Technical Specifications
ATENG 12395 — Silent Air Compressor Unit
Single-phase motor with 340 W.
Low noise level with 40 dB of maximum.
Boiler capacity: 9 l.
Maximum pressure: 8 bar or 0.8 MPa.
Maximum air flow: 50 l/min.
Safety relief valve.
Start/stop switch.
Double scale manometer psi and bar with a range from 0 to 12 bar to measure the air pressure before the air filter-regulator.
Air Filter-Regulator (FR):
Double scale manometer psi and bar with a range from 0 to 12 bar to measure the air pressure after the air filter regulator.
Air filter with drain valve.
Air pressure regulator from 0 to 8 bar.
6 mm quick release connector for pneumatic flexible tubes.
Oil level indicator.
The oil necessary to work is included.
