Single Cell Test Station For Hydrogen Energy Equipments

Manufactured by Atico Export under expert engineering guidance for reliable hydrogen energy research, testing, and technical training applications. Designed to provide precise control of gas flow, line and cell temperature, exhaust gas cooling, and back pressure for fuel cell testing and performance evaluation.

• 600(W) X 950(D) X 2000(H) mm

Mass Flow Control:

• Turndown Ratio: 1000:1
• Gas Mixing and Multi-Range Control Available (Excluding Bench-Top Models)

Line Temperature Control:

• Flexible Line Heating
• Maximum Temperature: 220°C

Cell Temperature Control:

• Air or Liquid Circulation System
• Heating and Cooling Functions
• Maximum Temperature: 220°C

Exhaust Gas Cooling:

• Exhaust Gas Cooling and Trap System
• Condensation Water and Gas Separation

Back Pressure Control:

• Maximum Pressure: 3.5 bar
• Pressure Control Stability: ±2 kPa

Options:

• Humidity Control: Gas Temperature Range from Room Temperature to 95°C
• Dew Point Range: Room Temperature to 95°C ±1°C
• Cell Voltage Monitoring: ±5 V per Channel
• Integrated AC Impedance Measurement System: 10 mHz to 10 kHz
