Single Cell Test Station For Hydrogen Energy Equipments

Manufactured by Atico Export under expert engineering guidance for reliable hydrogen energy research, testing, and technical training applications. Designed to support precise gas flow control, methanol circulation, temperature regulation, exhaust gas cooling, and cell performance monitoring for fuel cell laboratory testing.

• 700(W) X 950(D) X 2000(H) mm

Mass Flow Control:

• Turndown Ratio: 1000:1
• Gas Mixing and Multi-Range Control Available

Line Temperature Control:

• Flexible Line Heating

Cell Temperature Control:

• Cell Heater or Heated Methanol Supply

Exhaust Gas Cooling (Cathode):

• Exhaust Gas Cooling and Trap System
• Condensation Water and Gas Separation

Methanol Circulation System:

• Methanol Mixing Tank with Temperature Control
• Methanol Return and Supply Ports
• Methanol Concentration Sensor
• DI Water Supply

Options:

• Humidity Control: Gas Temperature Range from Room Temperature to 95°C
• Dew Point Range: Room Temperature to 95°C ±1°C
• Back Pressure Control (Cathode): Maximum 3.5 bar
• Pressure Control Stability: ±2 kPa
• Cell Voltage Monitoring: Up to 200 Channels, ±5 V per Channel
• Integrated AC Impedance Measurement System: 10 mHz to 10 kHz
