Mass Flow Control:
- Turndown Ratio: 1000:1
- Gas Mixing and Multi-Range Control Available
Line Temperature Control:
Cell Temperature Control:
- Cell Heater or Heated Methanol Supply
Exhaust Gas Cooling (Cathode):
- Exhaust Gas Cooling and Trap System
- Condensation Water and Gas Separation
Methanol Circulation System:
- Methanol Mixing Tank with Temperature Control
- Methanol Return and Supply Ports
- Methanol Concentration Sensor
- DI Water Supply
Options:
- Humidity Control: Gas Temperature Range from Room Temperature to 95°C
- Dew Point Range: Room Temperature to 95°C ±1°C
- Back Pressure Control (Cathode): Maximum 3.5 bar
- Pressure Control Stability: ±2 kPa
- Cell Voltage Monitoring: Up to 200 Channels, ±5 V per Channel
- Integrated AC Impedance Measurement System: 10 mHz to 10 kHz
