Stack Test Station For Hydrogen Energy Equipments

Manufactured by Atico Export under expert engineering guidance for reliable hydrogen energy research, testing, and technical training applications. Designed to support controlled gas flow, humidity, temperature, pressure, and cell loading for fuel cell testing and performance evaluation.

• 1000(W) X 1800(D) X 2000(H) mm

Mass Flow Control:

• Turndown Ratio: 1000:1
• Gas Mixing and Multi-Range Control Available (Excluding Bench-Top Models)

Furnace:

• Vertical Tube or Box Furnace

Humidity Control:

• Gas Temperature Range: Room Temperature to 95°C
• Dew Point Range: Room Temperature to 95°C
• Dew Point Accuracy: ±1°C

Line Heater:

• Direct Gas Heating
• Maximum Temperature: 600°C

Exhaust Gas Cooling:

• Air-Cooled Radiator or Water-Cooling Heat Exchanger

Back Pressure Control:

• Maximum Pressure: 3.5 bar
• Pressure Control Stability: ±2 kPa

Cell Loading Pressure Control:

• Spring Load or Automatic Pressure Control
• Maximum Load: 1000 kgf

Button Cell Jig:

• Alumina Tube and Holder Set

Planar Cell Jig:

• Metal (Inconel) Bipolar Plate Set
