Trim saw laboratory and Oilfield instruments

Bench top tool designed to cut preset core sample lengths. The preset sample lengths can be adjusted at any time by rearranging machined spacers to the desired length between the blades. The quality of the saw blade allows for extreme precision of the end face after trimming of 0.002 inch (5/100 mm). All wetted components are constructed from stainless steel and anodized aluminum for long lasting corrosion free operation. All bearings are sealed to insure long lasting free movement. The containment pans and splash guards are also constructed of heavy gauge stainless steel, anodized aluminum and corrosion free plastic. Recirculating coolant system is also available.

Saw blade diameter :

• 200 mm (8'')

Saw blade thickness :

• 2 mm

Core diameter :

• up to 2''

Core length :

• 2", 3" other upon request

Lubricants :

• water (usually), oil

Power supply :

• 220 VAC 1 phase 50 or 60 Hz

Motor power :

• 550 W, 3,000 RPM

Weight :

• 30 kg

Dimensions :

• 700 x 800 x 600 mm
