Ultra - Centrifugal Mill

Application :

• The Ultra Centrifugal Mill is a process and laboratory machine designed for grinding soft, medium-hard and brittle materials.

Capacity & Performance :

• Accepts feed size up to 12 mm
• End fineness up to 40 °m

Configuration :

• The machine can accommodate:
• 1 rotor of choice
• 1 ring sieve of choice

Standard Delivery Includes :

• Sample collecting pan (stainless steel)
• Infeed hopper (stainless steel)
• Security cabinet (steel)
• Stop / Start / Reset function
• Speed setting
• The security cabinet is designed for operator safety. If the two handles are opened, the grinding process stops immediately.

Ring Sieves Available :

• 0.20 mm / 0.25 mm / 0.50 mm / 0.75 mm / 1.00 mm / 1.50 mm / 2.00 mm / 3.00 mm / 4.00 mm / 5.00 mm / 6.00 mm

Ring Sieve Features :

• Made from stainless steel
• 0.20 mm to 2.00 mm with trapezoidal perforation
• 3.00 mm to 6.00 mm with round holes

Working Method :

• When the sample enters the grinding chamber, the shearing action between a rotor and a fixed grinding bar grinds the sample. Once the particles become smaller than the sieve aperture size, they pass through the ring sieve and fall into the collector bucket.

Power supply :

• 230V / 50 Hz

Rated power :

• 0.75 kW

Volume :

• 900 ml

Weight :

• 35 kg

Rotor :

• 6 / 12 / 24 teeth

Ring sieves :

• 200mm × 6.00 mm

Speed setting :

• 10,000 × 18,000 rpm

Collecting pan :

• Standard

Safety clip :

• 2

Micro switch :

• Standard according to CE
