Unconsolidated core mounting system laboratory and Oilfield instruments

The unconsolidated core mounting system amalgamates friable or unconsolidated materials into a heat-shrink Teflon tubing with dual end screens. First, the sample is compacted into the tubing by means of a hydraulically operated piston compactor. Next, a small controlled axial force is applied to enhance sediment cohesion. Lastly, a heat gun shrinks the Teflon tubing, finalizing the compaction.

Core diameter :

• 1", 1.5" (other upon request)

Core length :

• up to 2"

Screen :

• 316 Stainless steel

Heat shrinkable tubing :

• Teflon
