Wax deposition flow loop for stock tank oil system and trainers

The Wax deposition flow loop for stock tank oil system and trainers A studies the wax deposition phenomenon by circulating an oil sample in a loop and gradually reducing the temperature until reaching the Wax deposition flow loop for stock tank oil system and trainers. Essentially, the device is an excellent tool that rapidly generates accurate & reliable results and can be utilized to evaluate the performance of inhibitors or dissolving agents as well as performing quality control. The oil sample which can contain wax inhibitors, circulates in the loop using a recirculation pump whose flow rate is controlled by a flow meter. The sample is circulated inside the loop and pre-heated to a set temperature while the cooling bath progresses to its set temperature. Differential pressure and temperature are monitored and their derivatives over time are utilized to evaluate inhibitor efficiency.

Pressure :

• up to 100 psi

Temperature range :

• -20°C to +90°C

Sample volume :

• 500 cc

Test coil diameter :

• 1/8 inch

Flow rate :

• up to 30 mL/min

Material :

• Stainless steel

Power supply :

• 220 VAC, 50 Hz

• Easy operations
• Accurate flow, pressure and temperature measurements
