Xray transparent Titanium Special core analysis Instruments

The Xray transparent Titanium Special core analysis Instruments are standard hydrostatic type core holders employed in core flooding studies involving in-situ saturation monitoring. The core holder is made from a high grade titanium alloy to prevent strong X-ray attenuation. Spiral fluid distribution grooves at the core inlet are incorporated to minimise capillary end effects. The vessel can be provided with an external heating system to assure isothermal testing conditions up to 150°C.

Operating pressure rating :

• 10,000 psi, 15,000 psi

Operating temperature :

• up to 150°C

Fitting :

• 1/8" LP

Core diameter :

• Customer specified

Core length :

• Customer specified

Wetted parts :

• Stainless steel, Hastelloy, titanium

Body material :

• Titanium

Sleeve material :

• Viton

Inlet port :

• As request

Outlet port :

• one
