25-Litre Multipurpose Synthesis Unit

Chemical reaction is a fundamental operation in the chemical industry, enabling the production from simple molecules (reactants) of increasingly complex compounds for a growing number of industries (chemical, pharmaceutical, etc. ). Learning Objectives: Simple reactions. Learn about 25-Litre Multipurpose Synthesis Unit specifications for optimal educational outcomes.. Evaporation. Crystallisation by evaporation, chemical reaction, or cooling. Learn about 25-Litre Multipurpose Synthesis Unit suppliers for optimal educational outcomes.. Total reflux reactions. Batch distillation with partial condensation. Learn about Digital 25-Litre Multipurpose Synthesis Unit for optimal educational outcomes.. Batch distillation under reduced pressure. Mass balance. Learn about 25-Litre Multipurpose Synthesis Unit exporters for optimal educational outcomes.. Yields. Heat balance. Learn about 25-Litre Multipurpose Synthesis Unit price for optimal educational outcomes..

The reactor is of the perfectly mixed type and operates in batch mode: the reactant charge is introduced at the start all at once or controlled over time. The reaction mass is brought to the required temperature.

Graduated borosilicate glass reactant storage receiver with siphon system for filling.
Truncated-cone reactor with steam heating jacket, flush-mounted drain valve, and operator protection panel.
Fixed-speed 316L stainless steel agitation assembly with V-anchor impeller.
316L stainless steel column in one section with 316L stainless steel packing.
Vertical partial condenser, multitubular type.
Total condenser.
Cooler.
Graduated borosilicate glass distillate receivers.
Steam pressure reduction and regulation circuit with operator protection panel.
316L stainless steel interconnecting pipework.
316L stainless steel reduced-pressure piping for sub-assemblies on the common manifold.
Borosilicate glass vacuum trap.
316L stainless steel vent piping for sub-assemblies on the common manifold to central extraction.
316L stainless steel A3-format document holder.
Support frame in 304L stainless steel tubing.
Partial condenser cooling water supply with rotameter and flow control valve.
Total condenser cooling water supply with rotameter, flow control valve, and water circulation monitor to stop heating on coolant failure.
Reactor cooling water supply with rotameter and flow control valve.
Column pressure drop measurement via U-tube differential manometer.
Steam supply pressure gauges.
Reactant feed flow measurement via rotameter.
Reflux and distillate flow measurement via rotameters.
Reactor and pilot pressure gauges.
IP55 control and instrumentation cabinet with emergency stop, start/stop buttons, and two digital temperature indicators for eight Pt100 Ω probes.
