The Advanced AC Electrical Motors Application, to carry out electrical/mechanical test for a great variety of AC motors.
Technical Specifications
ATENG 11126 — Advanced AC Electrical Motors Application
The “ATENG 11126” application includes the following elements:
N-ALI01. Industrial Main Power Supply Module.
Supply voltage: 400 VAC, 3PH + N.
ON / OFF removable key.
Output voltage connections:
Three-Phase + Neutral: 400 VAC.
Single-Phase: 230 VAC.
Three-Phase supply hose with IP44 3PN + E 32 A 400 V connecting plug.
N-ALI01
Differential magnetothermal 4 poles, 25 A, 300 mA AC 6 KA.
Emergency stop push-button.
N-REL09. Time Electronic Relay against Overcurrents Module (0-16 A).
Overcurrent electronic relay.
Overload protection.
Range: 0 – 16 A.
Test and reset function.
NO / NC contact.
Timing. N-REL09
N-REL60. Single-Phase Over / Undercurrent Relay Module.
Overcurrent electronic relay.
Range: 0.05 – 10 A.
Reset and test function.
NO / NC contact.
Timing.
N-REL60
N-ARR12. Direct Starter Module.
Nominal voltage: 400 VAC.
Maximum contacts current: 10 A.
Two positions commutator (ON / OFF):
0: Open circuit.
1: Closed circuit.
N-EALD. Electrical Network Analyzer Module with Oscilloscope and Data Acquisition. N-ARR12
The network analyzer module allows fulfilling measurements, displaying and analyzing all
the parameters of the AC electrical networks. It has an LCD screen and push-buttons for the
navigation through the different menus. It includes specific software for monitoring current and
voltage curves, harmonics display, tariffs programming, alarms programming and electrical
parameters storage.
Features:
Multifunctional three-phase power meter:
Three-phase and single-phase voltage. Up to 690 VAC L-L. N-EALD
Line and neutral nominal current: 10 A.
Active, reactive and apparent power.
Suitable frequencies: 25 Hz, 50 Hz, 60 Hz and 400 Hz.
Display of the V-I vector diagram.
Supply voltage: 85 – 265 VAC.
Energy quality control:
Current and voltage individual harmonics measurement. Up to the 40th harmonic.
Voltage and current THD, TDD and K-Factor.
Maximums and minimums display.
Waveforms display, 128 samples/sec.
Events and data storage:
Harmonics analyzer:
Voltage and current THD, current TDD and K-Factor, up to the 40th harmonic.
Current and voltage harmonic spectrum and angles.
Tariff programming:
Class 0.5S IEC 62053 – 22, active and reactive power in four quadrants.
Measurement of the total and per phase three-phase active, reactive and apparent
powers.
Usage time, four energy/demand records of total tariffs.
Eight tariffs, four seasons and four types of days.
Automatic daily report of energy consumption maximums and minimums.
Communications:
RS – 485 communication port.
4
Specifications
N-MED09. AC Ammeter Module (0-2.5 A).
Measurement range: 0 – 2.5 A.
Terminals:
Measurement terminals.
N-MED11. AC Ammeter Module (0-10 A).
Measuring range: 0 – 10 A. N-MED09
Terminals:
Measurement terminals.
MED65. Digital Multimeter.
Digital multimeter with 3 ½ digits, with 4 mm double connector termination cables to facilitate
interconnections.
With this digital multimeter we will be able to measure:
N-MED11
Voltage.
Current.
Resistance.
Capacitors capacity.
Temperature.
TECNEL/TM. Hand Tachometer.
9 V battery. MED65
Three positions switch to choice the measurement method.
Speed recording push-button.
Speed measurement push-button.
Disassemble pieces for different shafts.
Speed digital display.
N-SERV1K. 1 kW Servomotor Module. TECNEL/TM
Dynamic and static operating regime in four quadrants.
Speed and torque signals.
Power supply terminals: 3 x 400 VAC.
Frequency: 50 / 60 Hz.
Nominal power: 1 kW.
Maximum power: 3 kW.
Maximum speed: 5000 rpm.
Nominal torque: 3.18 Nm.
Maximum torque: 9.55 Nm. N-SERV1K
Temperature control.
Speed control potentiometer.
Torque control potentiometer.
Mode selection switch: torque/speed control.
Motor turning reversal switch.
Required elements (at least one) (Not included):
ACEMT-K1:Three-Phase Asynchronous Motor of Squirrel Cage Kit.
