Aircraft ADF System Trainer

The Aircraft ADF System Trainer provides trainees with hands-on experience in operating and understanding aircraft ADF systems. The trainer provides practical training with aircraft ADF equipment configured to create a realistic training environment.

The system helps trainees develop an understanding of ADF equipment along with systematic troubleshooting and testing procedures. The trainer is delivered as a plug-and-play system with necessary antennas, transmitters, receivers, wiring and indicators.

Manufactured by Atico Export using carefully selected materials and controlled production processes for dependable educational laboratory use.

Components :

• ADF (Automatic Direction Finder)
• ADF Indicator
• ADF antenna with coaxial connector
• DC Power Box
• Circuit Breaker
• 20 A power supply
• Current and voltage meters
• Assembled and wired according to applicable aeronautical requirements
• Aeronautical standard connectors and jackets

Components Technical Specifications :

ADF Device General Specifications :

• Frequency range: 200 kHz to 1799 kHz in 1 kHz increments
• Bearing accuracy: ±3 degrees from 70 μV/m to 0.5 V/m RF input signal level
• Receiver sensitivity: 150 μV/m maximum for S+N/N = 6 dB
• Receiver selectivity:
  • 6 dB bandwidth: ±2 kHz maximum off center frequency
  • 80 dB bandwidth: ±7 kHz maximum off center frequency
• Power requirements: 11 to 33 VDC, 12 watts
• ADF button
• BFO button
• FRQ button
• FLT/ET button
• SET/RST button
• Volume/Off control
• Frequency display
• Installation manual

Documentation :

• User's Manual
• Study Guide
• Instructor's Guide
• Device's Original Manual
• Device's Original Wiring Diagrams
• Training Video for Teachers

Power Supply :

• Electrical box
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Required Items :

• NAV/COM tester for effectively testing the avionics system
• NAV/COM ramp tester for comprehensive system testing

Accessories :

• Instructor's Panel Control Box for Scenario and Fault Simulation

Manufacturing :

• Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

• Understanding of aircraft ADF fundamentals and system components
• System mounted on a metal/aluminum mobile stand
• Metal/aluminum frame with four wheels
• Two of the four wheels are lockable
• Training video for teachers
• Delivered fully assembled, tested and ready to operate
• Colored ultraviolet printing method on aluminum composite panel
