Aircraft Autopilot / Automatic Flight Controls & PFD Trainer

This trainer includes Autopilot, PFD, NAV and Directional Gyro systems, making it suitable for advanced avionics training. It provides an effective platform for teaching the principles of automatic flight controls through a complete system covering three-axis autopilot and automatic flight control functions.

The trainer allows students to observe aircraft control surface operation through the aircraft mock-up and provides practical training on autopilot, navigation, communication, EFIS, directional gyro, yoke and rudder pedal systems.

Manufactured by Atico Export under expert engineering guidance for reliable technical teaching and training applications.

Documentation :

• User's Manual
• Study Guide
• Instructor's Guide
• Device's Original Manual
• Device's Original Wiring Diagrams
• Training Video for Instructors

Power Supply :

• Electrical box
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Optional Items :

• Computer-Based Training Software

• Aircraft control surfaces operation can easily be seen from the aircraft mock-up on the trainer
• Autopilot control panel
• Three autopilot servos
• VHF NAV / COM radio
• COM, NAV, 10 Watts, 8.33 kHz
• VOR antenna
• VHF antenna
• Headset
• 10-inch touch display
• ADAHRS (Air Data and Attitude/Heading Reference System)
• Magnetometer
• OAT probe
• Configuration module
• Remote directional gyro control panel
• Gyro
• Analog gyro indicator
• Flux
• Yoke system
• Rudder pedal system
• System mounted on a metal/aluminum mobile stand
• Metal/aluminum frame with four wheels
• Two of the four wheels are lockable
