Aircraft DME System Trainer

The Aircraft DME System Trainer provides trainees with hands-on experience in operating and understanding aircraft Distance Measuring Equipment (DME) systems. The trainer delivers practical training using aircraft DME equipment configured to simulate a realistic aviation environment.

The system helps trainees develop a thorough understanding of DME equipment along with systematic troubleshooting and testing procedures. The trainer is delivered as a plug-and-play system with antennas, transmitters, receivers, wiring and indicators.

Engineered and manufactured by Atico Export for reliable performance in demanding technical training laboratories.

Components :

• Distance Measuring Equipment (DME)
• DME antenna with coaxial connector
• DC Power Box
• Aircraft Circuit Breaker
• Circuit Breaker Lockout
• Audio Jack
• 20 A Power Supply
• Current and Voltage Meters
• Aeronautical Standard Connectors and Jackets

Components Technical Specifications :

DME Device General Specifications :

• 200-channel receiver
• External control head with BCD, 2×5, slip code and serial code channeling
• RMT / FREQ / GS-T operating modes
• Dual concentric frequency control knob
• Digital frequency display
• Installation manual

Documentation :

• User's Manual
• Study Guide
• Instructor's Guide
• Device's Original Manual
• Device's Original Wiring Diagrams
• Training Video for Teachers

Power Supply :

• Electrical box
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Required Items :

• NAV/COM tester for effective testing of the DME avionics system
• NAV/COM ramp tester for comprehensive DME system testing

Accessories :

• Instructor's Panel Control Box for Scenario and Fault Simulation

Manufacturing :

• Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

• Understanding of aircraft DME fundamentals and system components
• 0–10 A DC current meter and 0–30 V DC voltmeter
• System mounted on a metal/aluminum mobile stand
• Metal/aluminum frame with four wheels
• Two of the four wheels are lockable
• Delivered fully assembled, tested and ready to operate
• Colored ultraviolet printing on aluminum composite panel
