+91 98967 93832This functional trainer demonstrates the electrical operation of landing gear. Its design is based on actual control circuits found in current aircraft.
| Specification | Details |
|---|---|
| Limit Switches | Uplock switch, Downlock switch, Throttle Switch |
| Indicators | Gear Up (Red), Gear Down (Green) |
| Controls | Gear Operation Lever, Simulated Throttle |
| Circuit Breakers | AC Mains to 28 VDC Power Supply, DC Master Power, Landing Gear Motor, Control Panel |
| Relays | Gear Motor Relay/Contactor, Ground Safety Switch Simulation |
| Ground Simulation | A moveable surface under the wheel simulates aircraft on ground |
| Warning | Audio Horn (below 33% Power when gear is up), Flasher Unit |
| Mobility | Mounted on four casters |
| Dimensions | Height: 48 inches, Width: 33 inches, Depth: 18 inches |
| Power Supply | 110 VAC 60 Hz or 220–240 VAC 50 Hz |
| Testing/Troubleshooting | All signals available on a terminal strip, Instructor's Panel for fault insertion |
| Training Documentation | Circuit diagram, Training Manual, Instructor's supplement |
