Aircraft Glass Cockpit Trainer Autopilot Module

The Aircraft Glass Cockpit Trainer Autopilot Module is an add-on module designed to work with the Aircraft Glass Cockpit Trainer. It allows trainees to observe aircraft attitude and flight control surface operation in both manual and autopilot modes.

The module is plug-and-play and communicates with the main trainer through an Ethernet cable. It incorporates degree-of-freedom servos for roll, pitch and yaw movements, along with control surface servos for the aileron, elevator, rudder and elevator pitch trim.

The aircraft mockup provides visible movement of the control surfaces, synchronized with the autopilot and yoke, making it suitable for practical demonstration and training of aircraft flight control and autopilot operation.

This module cannot operate independently and requires the Aircraft Glass Cockpit Trainer for operation.

Designed and manufactured by Atico Export to meet the practical requirements of modern technical education laboratories.

Aircraft Mockup Specifications :

• Minimum aircraft size: 1400 × 1300 mm
• Aircraft color: White
• Aileron and elevator in different colors
• Movable aileron and elevator
• Four autopilot servos: aileron, elevator, rudder and pitch trim
• Pitch / Yaw / Roll servos / pitch trim servo
• Two limit switches in servo
• One beacon light at the nose section of the model aircraft

Documentation :

• User’s Manual
• Instructor’s Guide
• Device’s Original Manual
• Training Video for Teachers

Power Specifications :

• Electrical box
• Residual current device
• Emergency Button
• Energy Signal Lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Optional Items :

• Computer-Based Training Software

• Add-on module for Aircraft Glass Cockpit Trainer
• Plug-and-play operation
• Communication with the main trainer through Ethernet cable
• Manual and autopilot operating modes
• Degree-of-freedom servos for roll, pitch and yaw maneuvers
• Control surface servos for aileron, elevator, rudder and elevator pitch trim
• Aileron and elevator can move
• Aileron and elevator operate in synchronization with autopilot and yoke
• Four autopilot servos for aileron, elevator, rudder and pitch trim
• Pitch, yaw, roll and pitch trim servo operation
• Two limit switches in each servo
• Servos operate in synchronization with autopilot and yoke
• DOF system operates in synchronization with autopilot and yoke
• Beacon light at the nose section of the model aircraft
• Requires Aircraft Glass Cockpit Trainer for operation
