+91 98967 93832This GPS trainer provides in-depth knowledge and hands-on experience to maintain and troubleshoot GPS equipment. It covers GPS principles, operation, and equipment circuitry.
| Specification | Details |
|---|---|
| GPS Features | Panel-mount IFR GPS capable of GPS approaches, easy-to-read map display, comprehensive navigation database, eight-channel parallel receiver, Direct-To feature, altitude input for accuracy, interfaces to CDI/HSI/RMI/fuel management/moving map/air data systems, operates on 11–33VDC, front-loading database card, stores up to 500 user-defined waypoints and 200 airport comments, B-RNAV compliant |
| GPS Simulator | Single-channel, single-frequency (L1) signal generator; RF output at GPS L1 (1575.42 MHz); C/A Gold Codes 1–1023; 50 bits/s GPS frame structure; ultra-high frequency stability; frequency adjustment ±1 kHz; signal power -175 to -75 dBm; 2 dB control resolution |
| Digital Data Inputs | Altitude (Gray Code), air data computer, fuel management system, heading |
| Additional | Computer interface for uploading regional GPS databases |
