+91 98967 93832Aircraft Hydraulic Landing Gear System Trainer offers effective hands-on training for aircraft landing gear system maintenance trainees.
It helps technicians develop practical skills for maintaining landing gear systems in accordance with applicable safety requirements. It displays the landing gear mechanism as found in actual aircraft and is designed to represent a landing gear system with components and assemblies of a typical hydraulic landing gear system.
The trainer features a complete wheel and tire assembly with hydraulic brake system, including master cylinder and brake pedal. The control unit includes control levers for landing gear and hydraulic flap, spoiler, landing gear and landing gear door operation. Indicators demonstrate up, down and in-transition conditions. A warning horn is also mounted on the control panel.
The trainer is mounted on a mobile stand to provide a clear view from all directions.
The Hydraulic Landing Gear System Module is a hydraulically powered landing gear system that requires hydraulic pressure from the main hydraulic power unit to operate. The landing gear module cannot be operated without the main hydraulic power unit.
Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.
Trainer Functions :
Trainer Processes :
Landing gear extension test process
Landing gear retraction test process
Hydraulic system functional test process
Hydraulic system leak test process
Hand pump test process
Accumulator test process
ECAM test process
Emergency system test process
Hydraulic Flap System
Brake System
Aircraft Wheel System
Hydraulic System Control
Lower ECAM on the main unit
Master Caution System
Aural Warning Horn Panel System
Trainer able to display the landing gear operating system of a regular aircraft
Digital sensor data and switch states used in the set
Throttle lever with associated components completes the warning circuit of gear-up warning horn
Accumulator and hand pump can control the landing gear
Wirings on the trainer are connected via terminals
Wires have clear identification labels
All wires are coded and labeled for troubleshooting
The system is mounted on a metal/aluminum mobile stand
Metal/aluminum frame with 4 wheels; 2 of 4 wheels are lockable
Delivered fully assembled, tested and ready to operate
Colored ultraviolet printing method on aluminum composite panel
Components :
Control Panel :
Lower EICAS or ECAM :
Documentation :
Power Specs :
Required Items :
Accessories :
