Aircraft Ice & Rain Protection & Control System Trainer

The Ice and Rain Protection System Trainer offers trainees the opportunity to physically see various components and the connections between them in a real-life-like mechanism.

It brings together all aspects of de-icing and rain protection systems on aircraft.

The trainer is manufactured with authentic aircraft components. It is mounted on a movable four-wheeled frame that can be positioned as necessary.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Components :

• Aircraft composite propeller blade with electrical de-ice boot
• Propeller heating timer control box
• Propeller slip ring
• Pneumatic de-ice boot
• Pump for pneumatic de-ice boot

Lower EICAS or ECAM :

• Bleed valve status

• Bleed line pressure

• Fuel flow indicator

• Switch position

• Valve status

• Bleed control panel

Windshield Wiper Control Panel :

• OFF position
• Park position
• Low and High position
• Panel is independent of other panels

Window Heat Panel :

• Left side and forward control

• Right side and forward control

• Panel is independent of other panels

• Wing and engine anti-ice control panel

• Windscreen wiper

• Windscreen wiper motor/actuator

• Windscreen wiper arm/blade

• Aircraft window with heating elements

• Temperature control thermostat

• Window heating timer control box

• Windshield de-icing alcohol dispensing system

• Water/alcohol pump

• Water/alcohol tank

• Sprayer

• Pitot tube with electrical heating elements

• Pitot tube heating timer control box

Documentation :

• User’s Manual
• Study Guide
• Instructor’s Guide
• Training video for teachers

Power Specs :

• Electrical box
• LAN connection point
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Optional Items :

• Pre-loaded Fault Panel Software with Laptop
• Computer Based Training Software

Required Items :

• Air Compressor: Maximum 90 PSI pressure outlet
• Water

• Understanding fundamentals of aircraft ice and rain protection and control system and its components
• Windshield heating system
• Pitot tube heating system
• The pitot tube is in a transparent protection area
• Propeller blade heating system
• Slip ring system for propeller principles is exhibited
• Drain mast heating system
• Pneumatic de-ice boot
• Windshield wiper system
• Windshield wiper is in a compartment with a transparent front part
• Windshield wiper automatically sprays water/alcohol onto the surface
• Water in the windshield wiper compartment is accumulated into the water/alcohol tank through the drain line
• Hoses and tubes used in the trainer are labeled according to aviation standards
• Wiring on the trainer is connected via terminals
• Wires have clear identification labels for each wire
• All wires are coded and labeled for troubleshooting
• The system is mounted on a metal/aluminum mobile stand
• Metal/aluminum frame with 4 wheels, 2 of which are lockable
• Delivered fully assembled, tested and ready to operate
• Colored ultraviolet printing method on aluminum composite panel
