Aircraft Oxygen System Trainer V.1

This training set is a fully functional typical aircraft oxygen system. The external filler valve includes an orifice which restrains the filling rate, and it is protected by a cap so that contamination is prevented when the charging line is not connected.

The pressure regulator in the system adjusts the pressure in the cylinder to an amount that is usable by the masks.

NOTE: Pilot mask type may be changed according to stock availability.

This trainer allows practical tasks to be performed according to EASE PART 147 ATA-35-00-00.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Components :

Control Panel :

• Crew Control illuminated pushbutton
• Mask MANUAL/AUTO control guarded switch
• Passenger status indicator
• High-altitude landing guarded illuminated pushbutton
• Timer reset illuminated push button
• Aural warning horn
• Master caution resettable illuminated push button

Master Power and Circuit Breaker Panel :

• Guarded Master Power Switch
• Crew Oxygen Supply Circuit Breaker
• Passenger System Circuit Breaker

7-inch Touchscreen (ECAM) :

• Oxygen pressure indicator

• Oxygen status indicator

• System control computer box

• DC power unit

• PSU (Passenger Service Unit)

• COG (Chemical Oxygen Generator)

• Oxygen Cylinder

• Cylinder Pressure Gauge

• System Pressure Sensor

• Pressure Regulator

• Control Valve

• Filler Valve

• Filler Coupling

Pilots’ Oxygen Mask :

• Mask door

• Mask test button

• Mask status indicator

• Pressure releasing button

• Crew Portable Oxygen Cylinder

• Passenger’s Portable Mask

• Passenger Drop-down Masks

• Aircraft circuit breaker

• Aircraft circuit breaker lockout

• LAN output

• Fault and instructor port

• Lockable fault and instructor box

• Terminals

• MRT

• Storage drawer

Documentation :

• User’s Manual
• Study Guide
• Instructor’s Guide
• Components Diagrams

Power Specs :

• Electrical box
• LAN connection point
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Required Items :

• Air Compressor: Maximum 90 PSI pressure outlet

Optional Items :

• Pre-loaded Fault Panel Software with Laptop
• Computer Based Training Software
• Manual Release Tool
