Analogue Cockpit Instrumentation System

The Analogue Cockpit Instrumentation System Trainer is a complete and fully functional simulation of a typical aircraft analogue cockpit. It includes essential flight, engine and pitot-static instruments for hands-on maintenance training and instructor demonstrations.

The trainer demonstrates the operating principles of gyros, altimeter and engine instruments and can be used for practical training in instrument removal and replacement. The system combines cockpit analogue flight instrumentation and engine instrumentation.

A three-degrees-of-freedom instrument panel permits full demonstration of attitude and directional gyro functions. The functional engine instrumentation system can be connected to engine sensors, while the analogue instruments operate manually. The trainer also provides engine sensor simulation, a pitot-static system and an instructor’s panel for fault insertion.

The trainer can be customized with sensors and indicators according to specific training requirements and supports practical tasks related to EASA Part 147 ATA-31-00-00.

Designed and manufactured by Atico Export to meet the practical requirements of modern technical education laboratories.

Components :

Analogue Instruments :

• Attitude Gyro and Indicator
• Directional Gyro / Heading Indicator
• Airspeed Indicator
• Altimeter
• Vertical Speed Indicator
• Turn and Slip Indicator
• Fuel Temperature/Pressure Indicator
• Oil Temperature/Pressure Indicators
• Fuel Level Indicator
• MAP
• RPM / Engine Tachometer
• Vacuum Gauge

Sensors :

• Oil Temperature Sensor
• Manifold Pressure Sensor
• Fuel Level Sensor
• Oil Pressure Sensor
• Fuel Pressure Sensor
• Engine RPM Sensor
• Ammeter Shunt
• Pitot Tube
• Static Port

Controls and Electrical Components :

• Aircraft circuit breakers
• Throttle Lever

Pitot-Static System :

• Pitot Tube
• Fuselage Static Port
• Alternate Static Port
• Static Source Selector Switch
• Two test ports for pitot-static test set

Power Functions :

• Main Power
• Tachometer
• Turn & Slip
• Vacuum Pump

Documentation :

• User’s Manual
• Study Guide
• Instructor’s Guide
• Device’s original Manual
• Device’s original Wiring Diagrams
• Training video for teachers

Power Specifications :

• Electrical box
• Residual current device
• Emergency Button
• Energy Signal Lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Required Items :

• Lighter
• Air compressor with maximum 90 PSI pressure outlet

Accessories :

• Instructor’s Panel Control Box for scenario and fault simulation

• Combines cockpit analogue flight instrumentation and engine instrumentation
• Three-degrees-of-freedom instrument panel for demonstration of attitude and directional gyro functions
• Functional engine instrumentation system connected to engine sensors
• Analogue instruments operate manually
• Primary flight display panel capable of simulating roll, pitch and yaw movements through a control-yoke-operated mechanism
• Provision for engine sensor simulation
• Pitot-static system
• Instructor’s panel for fault insertion
