BALANCE ANGLE FEEDBACK UNIT

Compact instrument that fixes to the Three Component Balance. It measures the angle positions of models mounted in the balance and feeds the information directly to a data acquisition system.

The Balance Angle Feedback Unit is an ancillary for use with a Three-Component Balance and data acquisition system together to measure and record the angular position of models mounted on the balance in subsonic wind tunnels. It mounts on the Three-Component Balance attached to the wind tunnel. It transmits the rotational angle of the model to a data acquisition system. Learn about BALANCE ANGLE FEEDBACK UNIT specifications for optimal educational outcomes.. The angle of the model can be logged on a suitable computer (not included) along with other captured experimental data. Note: the Angle Feedback Unit can only be used with the Three-Component Balance and a compatible data acquisition system. Learn about BALANCE ANGLE FEEDBACK UNIT aerodynamics India for optimal educational outcomes.. The unit is supplied with an input board for the data acquisition system.
