The Battery Energy Storage Test Application, to perform a complete characterization of the most common types of batteries. The is a computerized unit that allows the student to perform all battery tests in an automatic way and manage and save the obtained curves and charts for further analysis and comparisons.

ATENG 11590 — Battery Energy Storage Test Application

• The “ATENG 11590” application includes the following elements:
• BESTA-UB. Battery Energy Storage Test Base Unit.
• Battery discharge control: performs the steps to carry out the procedure selected in the
  computer for the different battery tests.
• Voltmeter and ammeter: measure the electric voltage and current from the tested battery. The
  values are visualized with the computer.
  BESTA-UB
• Load selector: different electric heating elements can be connected to the tested battery. The
  element is selected through the computer.
  Cable for connection with the computer.
• BAT3. Lithium-Iron-Phosphate Battery.
  Long life battery.
• Battery capacity: 2000 Wh.
• BAT5. Lead-Acid Battery.
  Sealed lead-acid battery.
• Required element (Not included):
• AEL-PC. Touch Screen and Computer.
• Touch screen:
• Energy efficiency class: A.
• Screen diagonal: 68.6 cm (27 inch (s)).
  AEL-PC
• Power consumption (operating): 26 watts.
• Annual energy consumption: 38 kWh.
  Power consumption (standby / off) 0.49 watts.
• Screen resolution: 1920 x 1080 pixels.
• Computer:
• Processor number: Intel Core i7-6600U Processor (4M Cache, up to 3,40 GHz).
• Cache: 4 MB Intel Smart Cache.
• Clock speed: 2.6 GHz.

• Of cores / # of threads: 2/4.

• Max. TDP / Power: 15 W.
• Memory types: DDR4-2133, LPDDDR3-1866, DDR3L-1600.
• Graphics: Intel HD graphics 530.
  Slot for PCI Express.
• All necessary cables to realize the practical exercises are included.
  Cables and accessories, for normal operation.
