Bearing & Lubrication Trainer

Trainees can learn about various types of bearings and lubrication, which are essential parts of aircraft engines, while gaining hands-on experience with lubrication procedures using the Bearing & Lubrication Training Set.

Trainees can also observe cutaway views of different bearings on the training set.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Components :

• Two (2) Types of Pillow Block Bearings
• One (1) Deep Groove Ball Bearing
• One (1) Cutaway Deep Groove Ball Bearing
• One (1) Spherical Roller Bearing
• One (1) Cutaway Spherical Roller Bearing
• One (1) Thrust Ball Bearing
• One (1) Cutaway Thrust Ball Bearing
• One (1) Taper Roller Bearing
• One (1) Cutaway Taper Roller Bearing
• One (1) Needle Roller Bearing
• Two (2) Linear Bearings
• Lubrication Area and Drain Line
• Five (5) Degreasing Sprays
• Grease and minimum two (2) Grease Pumps
• Five (5) Oilers

Documentation :

• User’s Manual

• The trainer allows trainees to understand the fundamentals of bearings and lubrication.
• Lubrication application area
• Greasing application area
• Comparator application area
• Drain line
• The system is mounted on a metal/aluminum mobile stand.
• Metal/aluminum frame with 4 wheels. 2 of 4 wheels are lockable.
• Colored ultraviolet printing method is used for all writings and drawings on the aluminum composite panel for improved durability and quality.
