Beechcraft Electrical Landing Gear Trainer

Electrical Landing Gear Trainer offers effective hands-on training for aircraft landing gear system maintenance trainees. It helps technicians develop practical skills for maintaining landing gear systems in accordance with applicable safety requirements.

It displays the landing gear mechanism as found in typical aircraft and is designed to represent an electrical landing gear system.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Control Panel :

• Landing Gear Down and Lock Lights

• Landing Gear Transition Light

• Lockable Landing Gear Lever

• Master Caution System

• Aural Warning Horn

• Circuit Breaker

• Aircraft Circuit Breaker Lockout

• Test Button

• Throttle lever with associated components completes the warning circuit

• Landing Gear Electric Motor

• Landing Gear Actuator

• Aircraft Wheel System

• Aircraft Tire Assembly (6 or 8 inch)

  • Aircraft Tire
  • Aircraft Wheel

• The system is mounted on a metal/aluminum mobile stand

• Metal/aluminum frame with 4 wheels; 2 of 4 wheels are lockable

• Delivered fully assembled, tested and ready to operate

• Colored ultraviolet printing method on aluminum composite panel

Documentation :

• Operations Manual
• Training Video for Instructors

Power Specs :

• Electrical box
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz

Upgrades :

• Wing cross-section containing electrically operated flap and spoiler surfaces
• Aircraft Systems Monitoring Display representing the ECAM/EICAS system in aircraft and used to check landing gear position

• Electrical Landing Gear Trainer able to display the landing gear operating system of a regular aircraft
• Landing gear actuator controlled via electrically driven motor
• Digital sensor data and switch states used in the set
• Wirings on the trainer are connected via terminals
• Wires have clear identification labels for each wire
• All wires are coded and labeled for troubleshooting
