Bicycle Brake Study Model

The bicycle brake model presents three commercial calipers offering specific mechanical characteristics, used on bicycles of very different usage types. This model is an ideal educational support both in terms of construction technology and static mechanics. Educational Objectives: Measure passive resistances, measure caliper clamping force, verify and compare performance of equivalent mechanical systems, use the fundamental principle of statics, choose and apply a graphical resolution method, validate hypotheses and adopted modeling. Learn about Bicycle Brake Study Model equipment for optimal educational outcomes..

The various experiments are performed on a real mechanism and link to the model. Composition

• Three commercial bicycle brake calipers mounted on a support plate and equipped with cables and handles
• CD-ROM with educational and technical resources (3D)
• Requires a dynamometer and a set of masses (to be ordered separately).

Three commercial bicycle brake calipers mounted on a support plate and equipped with cables and handles
CD-ROM with educational and technical resources (3D)
Requires a dynamometer and a set of masses (to be ordered separately)
