ATENG 11557 — Biogas Process Unit
Bench-top unit.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
- Two packed anaerobic digesters of 5 l. Reactors packing: 25 mm diameter bactoballs.
Two heating blankets of 120 W with a thermostat and a temperature probe to control the heating
- temperature. Temperature range: 0 – 90 °C.
Four peristaltic pumps.
Feeding flows measurement by the pumps calibration.
Two volumetric tanks for the storage and volume measurement of the generated biogas.
Buffer vessel, of 1 l of capacity.
Two glass vessels, of 1 l of capacity, for the acid and the base.
ATENG 11557 detail
Methane sensor to measure its concentration in the generated biogas, 0 – 100 %.
- Two pH meters, range: 0 – 14.
Two “J” type temperature sensors.
- Electronic console:
Metallic box.
Temperature sensors connections.
Digital display for the temperature sensors.
Selector for the temperature sensors.
Methane sensor connection.
Digital display for the methane sensor.
Pumps switches.
Pumps controllers.
Heating blankets switches.
Cables and Accessories, for normal operation.
