Building Control Training Application via BMS

The Building Control Training Application via BMS, is designed to provide knowledge and experience in KNX programming practices specifically tailored for building management systems (BMS).

ATENG 11104 — Building Control Training Application via BMS

• The ATENG 11096 Base Unit, “AEL-KNX-UB,” includes the following elements:
• N-KNX34. KNX/EIB USB Programming Interface Module.
• Power supply: KNX line, 21…30 VDC.
• Current consumption (max.): < 5 mA.
• USB connection: USB2.0 connector.
• N-KNX18. KNX/EIB Power Supply Module.
• Power supply: 230 VAC. N-KNX34
• Maximum load: 640 mA.
• Output voltage: 24 VDC.
• N-KNX4. KNX/EIB Binary Input Module.
• Nominal voltage: 230 VAC.
• Frequency: 50 Hz.
  N-KNX18
• KNX bus voltage: 24 VDC.
• Mains inputs/outputs: 4 mm safety sockets.
• Bus inputs/outputs: 2 mm safety sockets.
• N-KNX5. KNX/EIB Binary Output Module. (2 units).
• Nominal voltage: 230 VAC.
• Frequency: 50 Hz. N-KNX4
• KNX bus voltage: 24 VDC.
• Mains inputs/outputs: 4 mm safety sockets.
• Bus inputs/outputs: 2 mm safety sockets.
• N-KNX30. Módulo de Panel Táctil KNX/EIB.
• Nominal voltage: 230 VAC.
  N-KNX5
• Frequency: 50 Hz.
• KNX bus voltage: 24 VDC.
• Mains inputs/outputs: 4 mm safety sockets.
• Bus inputs/outputs: 2 mm safety sockets.
• N-KNX35. KNX/EIB Infrared Transmitter/Receiver Module.
• The IR remote is powered by two batteries of type alkaline (LR03/AAA; 1,5 V).
  N-KNX30
• Normal functions:
  Switching.
  Switching and dimming.
  Control of blinds.
• MED65. Digital Multimeter.
• Digital multimeter with 3 ½ digits, with 4 mm double connector termination cables to facilitate N-KNX35
  interconnections.
• With this digital multimeter we will be able to measure:
  Voltage.
  Current.
  Resistance.
  Capacitors capacity.
  MED65
  Temperature.
• Required elements of the ATENG 11096 Base Unit, “AEl-KNX-UB” (at least one) (Not included):
  ATENG 11098. KNX Lighting Control Training Application.
• N-KNX19. KNX/EIB Proximity Sensor Module.
• KNX bus voltage: 24 VDC.
• Bus inputs/outputs: 2 mm safety sockets.
• Working temperature: -5 °C to +45 °C.
  N-KNX19
  6

Specifications

• N-KNX20. KNX/EIB Push-Button Module.
  Pushbuttons can be programmed for 1 or 2-button operation.
  1 and 2 button operation for switching, dimming, blinds.
  Change of values / scenes with up to 4 values.
  Short/long push button and 2 object operation.
  Group control with long/long button press.
• N-LAM32. One LED Lamp Module. (4 units).
• Lamp led 24 VDC.
• N-KNX8. KNX/EIB Dimmer Actuator Module
  DALI dimmable driver.
• Power: 2 – 21 W.
  N-LAM32
• Input voltage: 230 VAC.
• Output voltage: 9 – 42 V.
• N-DKG. DALI-KNX Gateway Module.
• Input voltage: 240 VAC.
• Frequency: 50/60 Hz.
• Communication port protocol: DALI. N-DKG
• Gateway: KNX/DALI.
• N-DAC. DALI Controller Module.
  DALI input controller.
  4 independent inputs for floating contacts.
  For standard snap-action switch or circuit breaker connections.
  N-DAC
• Power supply via DALI line: 24 VDC.
  ATENG 11099. KNX for ATENG 11845 Control Training Application.
• N-KNX1. KNX/EIB Heating Actuator Module.
• Nominal voltage: 230 VAC.
• Frequency: 50 Hz.
• KNX bus voltage: 24 VDC.
• Mains inputs/outputs: 4 mm safety sockets.
  N-KNX1
• Bus inputs/outputs: 2 mm safety sockets.
• N-KNX17. N-KNX17. KNX/EIB Movement Sensor Module.
  Movement sensor for bus system KNX.
  Max. transmission range frontally 7 m.
• Number of channels: 1.
  N-KNX17
• N-KNX29. KNX/EIB Temperature Sensor Module.
• KNX bus voltage: 24 VDC.
• Bus inputs/outputs: 2 mm safety sockets.
• Range measurement: 0 – 40 °C (approx.).
• N-KNX33. KNX/EIB Window/Door Contact Module.
• KNX bus voltage: 24 VDC.
  N-KNX29
• Bus inputs/outputs: 2 mm safety sockets.
