+91 98967 93832This trainer provides full functional demonstration of the actual instruments used in aircraft.
| Specification | Details |
|---|---|
| Flight Instruments | Directional gyro, attitude gyro/indicator (artificial horizon), airspeed indicator, turn and slip indicator, altimeter, rate of climb indicator (VSI), suction gauge (if vacuum gyros used) |
| Pitot-Static System | Pitot tube, fuselage side static port, alternate static port, static source selector, two test ports, pitot and static test selector switches |
| Engine Instruments | Engine RPM indicator, manifold pressure gauge, oil temperature indicator, oil pressure (if electric gyros), suction gauge (if vacuum gyros) |
| Electronic Simulation | Oil temperature, manifold pressure, engine RPM, oil pressure |
| Controls | Yoke (roll/pitch/yaw), throttle lever, RPM control lever, altitude simulation control valve, climb/descent selector and simulation control valve, vacuum gauge |
| Miscellaneous | Vacuum filter and pump, vacuum pressure regulator, T&B vacuum regulator |
