Computer Controlled Geothermal (high enthalpy) Energy Unit

The Computer Controlled Geothermal (high enthalpy) Energy Unit, has the aim of introducing the student in a renewable energy, increasingly important.

ATENG 11530 — Computer Controlled Geothermal (high enthalpy) Energy Unit

(for main items)

• With this unit there are several options and possibilities:
• Main items: 1, 2, 3, 4, 5 and 6.
• Optional items: 7, 8, 9, 10 and 11.
• Let us describe first the main items (1 to 6):
• 1EG6C. Unit:
  Anodized aluminum frame and panels made of painted steel.
  The unit includes wheels to facilitate its mobility.
  Main metallic elements made of stainless steel.
  Diagram in the front panel with distribution of the
  elements similar to the real one.
• Condenser circuit:
  Water cooled exchanger to condense the working
  fluid at the outlet of the turbine and make the
• cycle start again: there is a coil inside through
  which tap cold water flows.
  Flow sensor to measure the cooling water flow
  through the coil.
  Pressure sensor to measure the pressure of the
  working fluid in the condenser.
• Evaporator circuit:
  Heat exchanger to extract the heat from the water
  previously heated by a heating element in a tank.
• Unit: ATENG 11530
  Tank with electrical heating element (with PID control from the computer (PC)).
  Computer controlled pump to drive the hot water to the evaporator.
  Pressure sensor to measure the pressure of the working fluid in the evaporator.
  Flow sensor to measure the hot water flow that crosses the exchanger to evaporate the working fluid.
• Turbine of 7000 rpm approx.
  Electrical generator.
  Electrical load.
  Computer controlled pump to drive the working fluid through the closed circuit.
  Flow sensor to measure the flow of working fluid through the closed circuit.
  Eleven “J type” temperature sensors, distributed along the process, to know the heat transfers occurred.
  Measurement from the computer of the power consumed by the generator's load.
  Computer controlled solenoid valve.
  Pressure switch to avoid overpressures.
• The complete unit includes as well:
  Advanced Real-Time SCADA and PID Control.
  Open Control + Multicontrol + Real-Time Control.
  Specialized Control Software based on LabVIEW.
  National Instruments Data Acquisition board (250 KS/s, kilo samples per second).
  Calibration exercises, which are included, teach the user how to calibrate a sensor and the
  importance of checking the accuracy of the sensors before taking measurements.
  Projector and/or electronic whiteboard compatibility allows the unit to be explained and
  demonstrated to an entire class at one time.
  Capable of doing applied research, real industrial simulation, training courses, etc.
  Remote operation and control by the user and remote control for technical support,
  are always included.
  Totally safe, utilizing 4 safety systems (Mechanical, Electrical, Electronic & Software).
  Designed and manufactured under several quality standards.
  Optional ICAI software to create, edit and carry out practical exercises, tests, exams,
  calculations, etc. Apart from monitoring user's knowledge and progress reached.
  This unit has been designed for future expansion and integration. A common expansion is
  the Scada-Net (ESN) System which enables multiple students to simultaneously
  operate many units in a network.
  3

Complete Technical Specifications (for main items)

• EG6C/CIB. Control Interface Box:
  The Control Interface Box is part of the SCADA system.
  Control interface box with process diagram in the front panel and with the same distribution that
  the different elements located in the unit, for an easy understanding by the student.
• All sensors, with their respective signals, are properly manipulated from -10V. to +10V. computer output.
  Sensors connectors in the interface have different pines numbers (from 2 to 16), to avoid
  connection errors.
  Single cable between the control interface box and computer.
  The unit control elements are permanently computer controlled, without necessity of
  changes or connections during the whole process test procedure.
  Simultaneous visualization in the computer of all parameters involved in the process.
  Calibration of all sensors involved in the process.
  Real time curves representation about system responses.
  Storage of all the process data and results in a file.
  Graphic representation, in real time, of all the process/system responses.
  All the actuators’ values can be changed at any time from the keyboard allowing the
  analysis about curves and responses of the whole process.
  All the actuators and sensors values and their responses are displayed on only one screen in the
  computer.
  Shield and filtered signals to avoid external interferences.
  Real time PID control with flexibility of modifications from the computer keyboard of
  the PID parameters, at any moment during the process.
  EG6C/CIB
  Real time PID and on/off control for pumps, compressors, heating elements, control valves, etc.
  Real time PID control for parameters involved in the process simultaneously.
  Proportional control, integral control and derivative control, based on the real PID mathematical
  formula, by changing the values, at any time, of the three control constants (proportional, integral
  and derivative constants).
  Open control allowing modifications, at any moment and in real time, of parameters involved in the
  process simultaneously.
  Possibility of automatization of the actuators involved in the process.
  Three safety levels, one mechanical in the unit, another electronic in the control interface and
  the third one in the control software.
• 3 DAB. Data Acquisition Board:
  The Data Acquisition board is part of the SCADA system.
  PCI Express Data acquisition board (National Instruments) to be placed in a computer slot. Bus
  PCI Express.
• Analog input:
  Number of channels= 16 single-ended or 8 differential. Resolution=16 bits, 1 in 65536.
• Sampling rate up to: 250 KS/s (kilo samples per second).
• Input range (V)=±10 V. Data transfers=DMA, interrupts, programmed I/0. DMA channels=6.
• Analog output:
  Number of channels=2. Resolution=16 bits, 1 in 65536.
• Maximum output rate up to: 900 KS/s.
• Output range (V)=±10 V. Data transfers=DMA, interrupts, programmed I/0. DAB
• Digital Input/Output:
• Number of channels=24 inputs/outputs. D0 or DI Sample Clock frequency: 0 to 100 MHz.
• Timing: Number of Counter/timers=4. Resolution: Counter/timers: 32 bits.
  The Data Acquisition board model may change at any moment, providing the same or better
  features than those required for the unit.
  4 EG6C/CCSOF. PID Computer Control + Data Acquisition + Data Management
• Software:
  The three softwares are part of the SCADA system.
  Compatible with actual Windows operating systems. Graphic and intuitive simulation of the process in
  screen. Compatible with the industry standards.
  Registration and visualization of all process variables in an automatic and simultaneous way.
  Flexible, open and multicontrol software, developed with actual windows graphic systems, acting
  simultaneously on all process parameters.
  Analog and digital PID control.
  PID menu and set point selection required in the whole work range.
  Management, processing, comparison and storage of data.
  Sampling velocity up to 250 KS/s (kilo samples per second).
  Calibration system for the sensors involved in the process.
  It allows the registration of the alarms state and the graphic representation in real time.
  Comparative analysis of the obtained data, after the process and modification of the conditions during EG6C/CCSOF
  the process.
  Open software, allowing the teacher to modify texts, instructions. Teacher’s and student’s
  passwords to facilitate the teacher’s control on the student, and allowing the access to different work
  levels.
  This unit allows the 30 students of the classroom to visualize simultaneously all the results
  and the manipulation of the unit, during the process, by using a projector or an electronic
  whiteboard.
  5 Cables and Accessories, for normal operation.
• 6Manuals:
• This unit is supplied with 8 manuals: Required services, Assembly and Installation, Interface and
  Control software, Starting-up, Safety, Maintenance, Calibration & Practices manuals.
• References 1 to 6 are the main items: ATENG 11530 + EG6C/CIB + DAB + EG6C/CCSOF + Cables and Accessories + Manuals are included
  in the minimum supply for enabling normal and full operation.
  4

COMPLETE TECHNICAL SPECIFICATIONS (for optional items)

Additionally to the main items (1 to 6) described, we can offer, as optional, other items from 7 to 11.

• All these items try to give more possibilities for:
  a) Industrial configuration. (PLC)
  b) Technical and Vocational Education configuration. (ICAI and FSS)
  c) Multipost Expansions options. (MINI ESN and ESN)
  a) Industrial configuration
• 7PLC. Industrial Control using PLC (it includes PLC-PI Module plus PLC-SOF Control Software):
• PLC-PI. PLC Module:
  Metallic box.
  Circuit diagram in the module front panel.
• Front panel:
• Digital inputs (X) and Digital outputs (Y) block:
  16 Digital inputs, activated by switches and 16 LEDs for confirmation (red).
  14 Digital outputs (through SCSI connector) with 14 LEDs for message (green).
• Analog inputs block:
• 16 Analog inputs (-10 V. to + 10 V.) (through SCSI connector).
• Analog outputs block:
• 4 Analog outputs (-10 V. to + 10 V.) (through SCSI connector).
• Touch screen:
  High visibility and multiple functions. Display of a highly visible status. Recipe function. Bar graph function. Flow display function. Alarm list.
  Multi language function. True type fonts.
• Back panel:
• Power supply connector. Fuse 2A. RS-232 connector to PC. USB 2.0 connector to PC.
• Inside:
• Power supply outputs: 24 Vdc, 12 Vdc, -12 Vdc, 12 Vdc variable.
• Panasonic PLC:
  High-speed scan of 0.32 µsec. for a basic instruction.
  Program capacity of 32 Ksteps, with a sufficient comment area.
• Power supply input (100 to 240 V AC).
• DC input: 16 (24 V DC).
• Relay output: 14.
  High-speed counter.
  Multi-point PID control.
  Digital inputs/outputs and analog inputs/outputs Panasonic modules.
  Communication RS232 wire to computer (PC).
• Dimensions: 490 x 330 x 310 mm. approx. (19.29 x 12.99 x 12.20 inches approx.). Weight: 30 Kg. approx. (66 pounds approx.).
• EG6C/PLC-SOF. PLC Control Software:
  For this particular unit, always included with PLC supply.
  The software has been designed using Labview and it follows the unit operation procedure and linked with the Control Interface Box used in the Computer
  Controlled Geothermal (high enthalpy) Energy Unit (ATENG 11530).
• Control Interface Data Software for:
• Box Acquisition - Computer Control
• Board - Data Acquisition
• Unit - Data Management

PLC CONTROL

PLC-SOF.

Control Software

PLC-PI. PLC Module

• Practices to be done with PLC-PI:
  1.- Control of the particular unit process through the control interface box 13.-PLC different programming standard languages (ladder diagram (LD),
  without the computer. structured text (ST), instructions list (IL), sequential function chart (SFC),
  2.- Visualization of all the sensors values used in the particular unit process. function block diagram (FBD)).
  3.- Calibration of all sensors included in the particular unit process. 14.-New configuration and development of new process.
  4.- Hand on of all the actuators involved in the particular unit process. 15.-Hand on an established process.
  5.- Realization of different experiments, in automatic way, without having in 16.-To visualize and see the results and to make comparisons with the
  front the particular unit. (These experiments can be decided previously). particular unit process.
  6.- Simulation of outside actions, in the cases do not exist hardware 17.-Possibility of creating new process in relation with the particular unit.
• elements. (Example: test of complementary tanks, complementary 18.-PLC Programming Exercises.
  industrialenvironment to the process to be studied, etc). 19.-Own PLC applications in accordance with teacher and student
  7.- PLC hardware general use. requirements.
  8.- PLC process application for the particular unit.
  9.- PLC structure.
  10.-PLC inputs and outputs configuration.
  11.-PLC configuration possibilities.
  12.-PLC program languages.
  6

Complete Technical Specifications (for optional items)

b) Technical and Vocational Education configuration

8 EG6C/ICAI. Interactive Computer Aided Instruction Software.

• This complete software package consists of an Instructor Software ( Classroom Manager - ECM-SOF) totally integrated with the
• Student Software ( Student Labsoft - ESL-SOF). Both are interconnected so that the teacher knows at any moment what is the theoretical and
  practical knowledge of the students.
  This software is optional and can be used additionally to items (1 to 6).
  Instructor Software
• ECM-SOF. Classroom Manager (Instructor Software).
  ECM-SOF is the application that allows the Instructor to register students,
  manage and assign tasks for workgroups, create own content to carry out
  Practical Exercises, choose one of the evaluation methods to check the
  Student knowledge and monitor the progression related to the planned
  tasks for individual students, workgroups, units, etc. so the teacher
  can know in real time the level of understanding of any student in the
  classroom.
• Innovative features: ECM-SOF. Classroom
  Manager (Instructor Software)
• User Data Base Management. Application Main Screen ECAL. Calculations Program Package -
  Formula Editor Screen
• Administration and assignment of Workgroup, Task and Training
  sessions.
• Creation and Integration of Practical Exercises and Multimedia
  Resources.
• Custom Design of Evaluation Methods.
• Creation and assignment of Formulas & Equations.
• Equation System Solver Engine.
• Updatable Contents.
  ERS. Results & Statistics
• Report generation, User Progression Monitoring and Statistics. Program Package - Student
  Scores Histogram ETTE. Training Test & Exam Program
• Package - Main Screen with Numeric Result
  Question
• ESL-SOF. Student Labsoft (Student Software).
  ESL-SOF is the application addressed to the Students that helps them Student Software
  to understand theoretical concepts by means of practical exercises
  and to prove their knowledge and progression by performing tests and
  calculations in addition to Multimedia Resources. Default planned tasks
  and an Open workgroup are provided by to allow the students
  start working from the first session. Reports and statistics are available
  to know their progression at any time, as well as explanations for every
  exercise to reinforce the theoretically acquired technical knowledge.
• Innovative features:
• Student Log-In & Self-Registration.
  ESL-SOF. Student
  LabSoft (Student Software)
• Existing Tasks checking & Monitoring.
  Application Main Screen
  EPE. Practical Exercise Program Package
• Default contents & scheduled tasks available to be used from the Main Screen
  first session.
• Practical Exercises accomplishment by following the Manual
  provided
• Evaluation Methods to prove your knowledge and progression.
• Test self-correction.
• Calculations computing and plotting.
• Equation System Solver Engine.
• User Monitoring Learning & Printable Reports.
  ERS. Results & Statistics
• Multimedia-Supported auxiliary resources. Program Package - Question
  Explanation
  ECAL. Calculations Program Package
  Main Screen
• For more information see ICAI catalogue. Click on the following link:

7

Complete Technical Specifications (for optional items)

9 EG6C/FSS. Faults Simulation System.

Example of some screens

Faults Simulation System (FSS) is a Software package that simulates

several faults in any Computer Controlled Unit. It is useful for

Technical and Vocational level.

The “FAULTS” mode consists in causing several faults in the unit

normal operation. The student must find them and solve them.

There are several kinds of faults that can be grouped in the following

• sections:
• Faults affecting the sensors measurement:
• An incorrect calibration is applied to them.
• Non-linearity.
• Faults affecting the actuators:
• Actuators channels interchange at any time during the program
  execution.
• Response reduction of an actuator.
• Faults in the controls execution:
• Inversion of the performance in ON/OFF controls.
• Reduction or increase of the calculated total response.
• The action of some controls is annulled.
• On/off faults:
• Several on/off faults can be included.
• For more information see FSS catalogue. Click on the following link:

c) Multipost Expansions options

10MINI ESN. Mini Scada-Net System for being used with

Teaching Units.

MINI ESN.

MINI ESN. Mini Scada-Net System allows up to 30 students to work Mini Scada-Net System

with a Teaching Unit in any laboratory, simultaneously. It is useful for both,

Higher Education and/or Technical and Vocational Education.

The MINI ESN system consists of the adaptation of any Computer

Controlled Unit with SCADA and PID Control integrated in a local network.

1 UNIT= up to 30

This system allows to view/control the unit remotely, from any computer STUDENTS can work

integrated in the local net (in the classroom), through the main computer simultaneously

connected to the unit. Then, the number of possible users who can work with

the same unit is higher than in an usual way of working (usually only one).

• Main characteristics:
• It allows up to 30 students to work simultaneously with the
  Computer Controlled Unit with SCADA and PID Control, connected
  in a local net. Computer Controlled Geothermal (high enthalpy) Energy Unit (ATENG 11530)
• Open Control + Multicontrol + Real Time Control + Multi Student
  Post.
• Software for:
• Instructor controls and explains to all students at the same time. Control - Computer Control
• Interface Box - Data Acquisition
• Any user/student can work doing “real time” control/multicontrol - Data Management
  and visualisation.
• Instructor can see in the computer what any user/student is doing Instructors'
  in the unit. Central Mini Scada-Net
  Computer
• Continuous communication between the instructor and all the Software
  users/students connected.
• Main advantages:
  LOCAL NET FOR 30 STUDENTS
• It allows an easier and quicker understanding.
• This system allows you can save time and cost.
• Note: The MINI ESN
• Future expansions with more Units.
  system can be used with
  any computer
  controlled unit
• For more information see MINI ESN catalogue. Click on the following link:

11ESN. Scada-Net Systems.

This unit can be integrated, in the future, into a Complete Laboratory with many Units and many Students.

• For more information see ESN catalogue. Click on the following link:

8

TENDER SPECIFICATIONS (for main items)

• 1EG6C. Unit:
  Anodized aluminum frame and panels made of painted steel.
  The unit includes wheels to facilitate its mobility.
  Main metallic elements made of stainless steel.
  Diagram in the front panel with distribution of the elements similar to the real one.
• Condenser circuit:
• Water cooled exchanger to condense the working fluid at the outlet of the turbine and make the cycle start again: there is a coil inside through which
  tap cold water flows.
  Flow sensor to measure the cooling water flow through the coil.
  Pressure sensor to measure the pressure of the working fluid in the condenser.
• Evaporator circuit:
  Heat exchanger to extract the heat from the water previously heated by a heating element in a tank.
  Tank with electrical heating element (with PID control from the computer).
  Computer controlled pump to drive the hot water to the evaporator.
  Pressure sensor to measure the pressure of the working fluid in the evaporator.
  Flow sensor to measure the hot water flow that crosses the exchanger to evaporate the working fluid.
• Turbine of 7000 rpm approx.
  Electrical generator.
  Electrical load.
  Computer controlled pump to drive the working fluid through the closed circuit.
  Flow sensor to measure the flow of working fluid through the closed circuit.
  Eleven “J type” temperature sensors, distributed along the process, to know the heat transfers occurred.
  Measurement from the computer of the power consumed by the generator's load.
  Computer controlled solenoid valve.
  Pressure switch to avoid overpressures.
• The complete unit includes as well:
  Advanced Real-Time SCADA and PID Control.
  Open Control + Multicontrol + Real-Time Control.
  Specialized Control Software based on LabVIEW.
  National Instruments Data Acquisition board (250 KS/s, kilo samples per second).
  Calibration exercises, which are included, teach the user how to calibrate a sensor and the importance of checking the accuracy of the sensors before
  taking measurements.
  Projector and/or electronic whiteboard compatibility allows the unit to be explained and demonstrated to an entire class at one time.
  Capable of doing applied research, real industrial simulation, training courses, etc.
  Remote operation and control by the user and remote control for technical support, are always included.
  Totally safe, utilizing 4 safety systems (Mechanical, Electrical, Electronic & Software).
  Designed and manufactured under several quality standards.
  Optional ICAI software to create, edit and carry out practical exercises, tests, exams, calculations, etc. Apart from monitoring user's knowledge and
  progress reached.
  This unit has been designed for future expansion and integration. A common expansion is the Scada-Net (ESN) System which enables multiple
  students to simultaneously operate many units in a network.
• 2EG6C/CIB. Control Interface Box:
  The Control Interface Box is part of the SCADA system.
  Control interface box with process diagram in the front panel.
  The unit control elements are permanently computer controlled.
  Simultaneous visualization in the computer of all parameters involved in the process.
  Calibration of all sensors involved in the process.
  Real time curves representation about system responses.
  All the actuators’ values can be changed at any time from the keyboard allowing the analysis about curves and responses of the whole process.
  Shield and filtered signals to avoid external interferences.
  Real time PID control with flexibility of modifications from the computer keyboard of the PID parameters, at any moment during the process.
  Real time PID control for parameters involved in the process simultaneously.
  Proportional control, integral control and derivative control, based on the real PID mathematical formula, by changing the values, at any time, of the three
  control constants (proportional, integral and derivative constants).
  Open control allowing modifications, at any moment and in real time, of parameters involved in the process simultaneously.
  Three safety levels, one mechanical in the unit, another electronic in the control interface and the third one in the control software.
• 3DAB. Data Acquisition Board:
  The Data Acquisition board is part of the SCADA system.
  PCI Express Data acquisition board (National Instruments) to be placed in a computer slot.
• Analog input: Channels= 16 single-ended or 8 differential. Resolution=16 bits, 1 in 65536. Sampling rate up to: 250 KS/s (kilo samples per second).
• Analog output: Channels=2. Resolution=16 bits, 1 in 65536.
• Digital Input/Output: Channels=24 inputs/outputs.
  The Data Acquisition board model may change at any moment, providing the same or better features than those required for the unit.
• 4EG6C/CCSOF. PID Computer Control +Data Acquisition+Data Management Software:
  The three softwares are part of the SCADA system.
  Compatible with the industry standards.
  Flexible, open and multicontrol software, developed with actual windows graphic systems, acting simultaneously on all process parameters.
  Analog and digital PID control. PID menu and set point selection required in the whole work range.
  Management, processing, comparison and storage of data.
  Sampling velocity up to 250 KS/s (kilo samples per second).
  Calibration system for the sensors involved in the process.
  It allows the registration of the alarms state and the graphic representation in real time.
  Open software, allowing the teacher to modify texts, instructions. Teacher’s and student’s passwords to facilitate the teacher’s control on the student, and
  allowing the access to different work levels.
  This unit allows the 30 students of the classroom to visualize simultaneously all the results and the manipulation of the unit, during the process, by using
  a projector or an electronic whiteboard.
  5Cables and Accessories, for normal operation.
• 6Manuals:
• This unit is supplied with 8 manuals: Required services, Assembly and Installation, Interface and Control software, Starting-up, Safety, Maintenance,
  Calibration & Practices manuals.
  10

Tender Specifications (for main items)
