Computer Controlled Teaching Curdling Tank

The Computer Controlled Teaching Curdling Tank, is employed to curdle milk in a tank with a water jacket and includes a set of accessories for the stirring, cutting and draining of the product.

CCDC — Computer Controlled Teaching Curdling Tank

(for main items)

• With this unit there are several options and possibilities:
• Main items: 1, 2, 3, 4, 5 and 6.
• Optional items: 7, 8, 9, 10 and 11.
• Let us describe first the main items (1 to 6):
• 1 CCDC. Unit:
  Metal frame with adjustable legs.
  Main metallic elements made of stainless steel.
  Diagram in the front panel with distribution of the
  elements similar to the real one.
  Curdling tank, dutch model, rectangular with
• semicircular ends. Material: stainless steel, capacity:
• 500 l. It includes:
  Bridge with shifter-gearmotor group for automatic
  curd cutting and stirring.
  Water jacket with stainless steel coil to heat water in
  the jacket using water or steam in a closed circuit.
  Two temperature sensors to measure the water and
  milk temperature.
  Filling/draining inlet for the water in the jacket and
  outlet valve for the whey.
  Overflow.
  Curd knives and stirrer and rising and prepressing plates
  attachable to the mechanized bridge.
• Two transparent guards with safety interlock protect students and allow the visibility of the practical Unit: CCDC
