Flight Control Cable Rigging

The Flight Control Cable Rigging Trainer is a lightweight, hands-on trainer that can be used to practice aircraft control surface alignment, push-pull rod adjustments, and related rigging procedures.

It is an efficient trainer for understanding the basics of how flight control cables operate. The unit can be easily moved between classrooms or workshops with the help of its caster wheel mechanism and lightweight construction.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Components :

• Yoke
• Control Surfaces
• Push-Pull Rods
• Bell Cranks
• Control Cables
• Drawer

Construction :

• The system is mounted on a metal/aluminum mobile stand.
• Metal/aluminum frame with 4 wheels. 2 of 4 wheels are lockable.

Documentation :

• General Info Manual

Optional Item :

• Cable Tensionmeter Gauge

• Lightweight portable frame
• Represents control surfaces and yoke operation
• Spring feel unit
• Bell cranks, push-pull rods, and pulleys
• Understanding flight control cable operation
• Understanding control surface operation
• Practice cable tension adjustment
• Practice control cable inspections
• Practice push-pull rod adjustment
• Control stops
• Turnbuckle
• Delivered fully assembled, tested, and ready to operate
