Flow Measurement Methods Study Apparatus

This bench sensitises students to common flow measurement methods and to the application of Bernoulli's theorem for an incompressible fluid. Learning Objectives: Application of Bernoulli's theorem for an incompressible fluid. Flow measurement using a Venturi tube, an orifice plate, and a rotameter. Learn about Flow Measurement Methods Study Apparatus India for optimal educational outcomes.. Comparison with volumetric measurement. Determination of pressure drops for each measurement system, for a sudden expansion, and for a 90° bend. Learn about Flow Measurement Methods Study Apparatus price for optimal educational outcomes..

1 tank with graduated gauge and lateral draw-off. 1 feed tank with drain.

1 tank fitted with a graduated gauge for level measurement with lateral draw-off.
1 feed tank with drain valve.
1 return tank.
One circulator.
One Venturi tube, diameters 26–16–26 mm.
One acrylic orifice plate, diameter 20 mm.
One sudden expansion from 26 to 50 mm.
One 90° elbow.
One rotameter.
One millimetre-scaled panel.
One set of piezometric tubes for pressure drop measurement.
One flow control valve downstream of the rotameter.
IP66 pump control and protection cabinet.
All pipework in PVC and acrylic (Venturi, orifice plate, and elbow) mounted on a stainless steel frame with aluminium fittings. Bench fitted with castors.
