FLOW ROUND A BEND

Allows students to measure the pressure distribution in a smooth rectangular bend via tapping points on the curved walls and radius.

One of a series of eight experiment modules that fit to the Modular Air Flow Bench, this module consists of a smooth rectangular bend with ten static tapping points on both the inner and outer curved walls, plus a further nine along the radius. Each one of the tapping points has a flexible tube with quick-release connector for connection to the Multi-tube Manometer ancillary. When air passes through the bend it creates areas of high and low pressure. Learn about FLOW ROUND A BEND aerodynamics India for optimal educational outcomes.. The resulting pressure plots on the multi-tube manometer are highly visual which enhances student understanding. The readings allow the students to plot the pressure profile and calculate a value for the loss coefficient (K). Learn about FLOW ROUND A BEND suppliers for optimal educational outcomes..
