Fluid Dynamics Study Bench Deluxe

This fluid dynamics bench verifies the fundamental laws of hydraulics in closed conduits. It generates different types of steady flow for quantitative study of pressure drop variations as a function of flow rate. Learning Objectives: Flow measurement using a calibrated orifice plate. Learn about Fluid Dynamics Study Bench specifications for optimal educational outcomes.. Study of distributed pressure drops along a 1-metre pipe with 3 pressure tappings. Study of minor losses in: orifice plate; 90° small- and large-radius elbows; 45° elbows; T-junction; sudden contraction; sudden expansion. Learn about Fluid Dynamics Study Bench for educational labs for optimal educational outcomes.. Visualisation of the laminar-to-turbulent transition by dye injection.

The bench consists of base elements to which the components under study are fixed. Each component is fitted with pressure tappings connected to a vertical multi-manometer with a millimetre scale.
