Fluidized Bed Drying Pilot Unit

Drying aims to eliminate by vaporization the liquid impregnating a solid. It follows operations such as sedimentation, filtration or centrifugation which separate the solid from the liquid but cannot remove residual moisture. Pedagogical Objectives: Study of convection drying of food or pharmaceutical products. Learn about Fluidized Bed Drying Pilot Unit manufacturers for optimal educational outcomes.. Study of the influence of product load, air inlet temperature and air flow rate. Measurement and control of inlet air temperature. Learn about Fluidized Bed Drying Pilot Unit suppliers for optimal educational outcomes.. Measurement of outlet air temperature. Measurement of product temperature. Learn about Fluidized Bed Drying Pilot Unit exporters for optimal educational outcomes.. Measurement of differential pressure across the distributor. Measurement of inlet air flow by anemometry (option). Learn about Fluidized Bed Drying Pilot Unit India for optimal educational outcomes.. Product sample collection. Measurement of inlet and outlet air humidity. Learn about Fluidized Bed Drying Pilot Unit specifications for optimal educational outcomes..

Technical Description:

• 1. 1 kW fan, maximum flow rate 610 m³/h, with speed variator
• 6,000 W electric heater controlled by PID regulator

1.1 kW fan, maximum flow rate 610 m³/h, with speed variator
6,000 W electric heater controlled by PID regulator
1.54 L product bowl with interchangeable screen and polycarbonate or stainless steel expansion zone with polycarbonate sight glass
Fluidized bed diameter: 200 mm, height: 1,000 mm
Sample port: nozzle on product bowl with sliding tube for in-process sampling for moisture analysis
Mechanical locking of product bowl
Air inlet with pre-filter
Filter at fluidized bed outlet
Flexible sleeve for hot, humid air ducting to exterior
Temperature and humidity measurement at column inlet and outlet
Differential pressure measurement upstream/downstream of air distributor
Product temperature measurement
Safety thermostat
Column inlet temperature regulated by adaptive and programmable digital PID regulator
Air velocity measurement by aerofoil profile probe
Electrical control cabinet including: heating element on/off button; inlet air temperature regulator; air speed adjustment potentiometer; parameter display on touchscreen; safety elements: emergency stop, circuit breakers, transformers, indicator lights
Heating element on/off button
Inlet air temperature regulator
Air speed adjustment potentiometer
Parameter display on touchscreen
Safety elements: emergency stop, circuit breakers, transformers, indicator lights
