Hands On Training Set

The Hands-On Training Set contains three trainers in one unit: Aircraft Safety Wire Trainer, O-Ring Application Trainer, and Bearing & Lubrication Trainer.

It is designed for hands-on laboratories in aviation maintenance schools. Five (5) students can work simultaneously on the trainer. Three students can practice safety wiring, one student can practice O-ring tasks, and one student can practice bearing and lubrication tasks.

Because of its compact design, the trainer can also be used as a practical examination trainer containing multiple practical tasks without any time delay between students.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Safety Wire :

• Understanding fundamentals of safety wire and its components.
• Metal durable box to simulate different areas on a typical aircraft
• Turnbuckle wiring application
• Fire tube clamp wiring application
• Push-pull rod castle nut cotter pin application
• Cotter pin safety wire application
• Guarded switch safety wire application
• Electrical connector safety wire application
• Fittings safety wire application
• Angled plates and bolts
• Side aluminum panel for propeller flange bolt order safety wire application
• Side aluminum panel for standard bolt order safety wire application
• HELICOIL application aluminum plate
• Three (3) different safety wire samples

Bearing and Lubrication :

• The trainer allows trainees to understand the fundamentals of bearing and lubrication applications.
• Lubrication area
• Greasing application area
• Comparator application area
• Drain line

O-Ring :

• Understanding fundamentals of aircraft O-rings
• O-ring and sealing application practices
• Normal and upside-down sealant or gasket application areas
• Cylinder O-ring application
• Common O-ring types displayed in the set
• Ten (10) application points in the set for practice
• Transparent and aluminum application points for sealing

Components :

• Aluminum Parts
• Drilled Bolts
• Aviation Standard Safety Wire Twisters (2 Pieces)
• Aviation Standard 0.20/0.22 or 0.32 Safety Wires (3 Boxes)
• HELICOIL Set (M5, M6, M8, M10, M12)
• HELICOIL Removing Tool (M3-M10)
• Two (2) Types of Pillow Block Bearings
• One (1) Deep Groove Ball Bearing
• One (1) Cutaway Deep Groove Ball Bearing
• One (1) Spherical Roller Bearing
• One (1) Cutaway Spherical Roller Bearing
• One (1) Thrust Ball Bearing
• One (1) Cutaway Thrust Ball Bearing
• One (1) Taper Roller Bearing
• One (1) Cutaway Taper Roller Bearing
• One (1) Needle Roller Bearing
• Two (2) Linear Bearings
• Five (5) Degreasing Sprays
• Two (2) Grease Pumps
• Five (5) Oilers
• Comparator with Accessories
• Fifteen (15) Different Types of O-Rings
• Ten (10) Practice Components
• Inch and Metric Full O-Ring Box
• Tube Liquid Seals
• O-Ring Extractor Tool Kits
