+91 98967 93832The Landing Gear Mechanism Trainer is very valuable hands-on training equipment for aircraft maintenance training schools. It is essential to ensure that trainees not only understand the theory but they are also well prepared to maintain the landing gear system in the best possible manner, and in compliance with the prevailing safety standards.
| Specification | Details |
|---|---|
| Features | |
| Tire Assembly | Wheel, Tires, Filter, Fluid Reservoir, Actuating Cylinder |
| Hydraulic Brake Components | Master Brake Cylinder, Fluid Reservoir, Brake Assembly |
| Hydraulically Operated Landing Gear | Electrically Driven Hydraulic Pump, Emergency Hand Pump, Relief Valves |
| Hydraulic-operated Flap | Actuating Cylinder, Control Lever, Flap Position Indicator |
| Hydraulically Operated Landing Gear Door | Door Actuator, Sequencing Valve |
| Components | Hydraulically operated retractable landing gear with operational strut, hydraulically operated landing gear door, sequencing controlled through squat switches and sequencing valves, all components mounted on display panel for clear student view, full function brake system with parking brake operation |
| Landing Gear Indication | Gear up, gear down, and in-transit |
| Additional Features | Throttle lever with associated components for gear up warning circuit, emergency hand pump, accumulator, powder coated finish, swivel casters with brakes |
| Power | 220VAC 50Hz or 110VAC 60Hz, single phase |
| Training | Computer-based training (CBT) included |
