+91 98967 93832This trainer incorporates all aspects of de-icing and rain protection systems found in an aircraft. Students can physically see the various components and assemblies and understand the interaction between them.
| Specification | Details |
|---|---|
| Sub-systems | Six separate sub-systems |
| Windshield Wiper System | Windscreen wiper, motor, actuator, wiper arm and blade |
| Windshield Heating System | Windshield with heating elements, temperature control thermostat |
| Windshield De-Icing (Alcohol Dispensing) | Alcohol tank, alcohol pump, sprayer, flow regulator |
| Pitot Heating | Pitot tube with electrical heating elements |
| Propeller De-Icing System | Electrically heated, de-ice timer (34 sec.), brush block, prop slip ring, ammeter, de-ice indicator, propeller blade with de-ice boot |
| Pneumatic De-Ice Boot System | Vacuum pump, filter assembly, regulator valve, suction gauge, boot pressure gauge, control valve |
