Laminar and Turbulent Flow Regime Study Bench

This bench enables determination of the characteristic quantities of laminar and turbulent flow regimes. Learning Objectives: Measurement of pressure drop and velocity in the tube and determination of the Reynolds number. Determination of the critical Reynolds number. Learn about Laminar and Turbulent Flow Regime Study Bench price for optimal educational outcomes.. Calculation of friction equations from the Darcy and Blasius equations.

The unit consists of a 3 mm diameter tube through which water is circulated, either by a pump or by an elevated tank. Feed pump.

One feed pump.
One elevated tank above the work surface.
One horizontal tube, 500 mm length and 3 mm internal diameter.
One flow control valve.
One U-tube manometer on a panel with a hand back-pressure pump.
One feed tank with lateral draw-off and drain valve.
One pump start/stop and protection control box.
Assembly mounted on a stainless steel frame with aluminium fittings.
