Lever Espagnolette Bolt

The lever espagnolette bolt equips the semi-fixed leaf of double doors. Hands-on manipulation and observation of the cross-section model with 3D CAD files allow students to understand the main shapes and proportions of the parts making up the bolt. It is perfectly suited for studying motion transformations. Learn about Lever Espagnolette Bolt for educational labs for optimal educational outcomes.. Educational Objectives: Visualize internal technical functions, observe motion transformations, apply technical communication tools, understand and assimilate associated technical vocabulary, raise awareness of conventions and graphic quality.

Composition

• A standard bolt mounted on a support plate
• A standard degreased bolt for disassembly and hands-on use
• CD-ROM with educational and technical resources (3D)

A standard bolt mounted on a support plate
A standard degreased bolt for disassembly and hands-on use
CD-ROM with educational and technical resources (3D)
