Micro Switch Training Set

Model: ATTE194Category: Aerospace Engineering Lab Trainers

Need Help?

Product Overview

The trainer allows trainees to understand the fundamentals of micro-switches. The trainer includes 5 different types of micro-switches commonly used with pneumatic systems.

Delivered fully assembled, tested, and ready to operate.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Technical Specifications

Components :

Aircraft Circuit Breaker.
5 different micro-switches:
- Long Lever.
- Short Lever.
- Roller Lever (2 different types).
- Limit Switch.
Pneumatic Filter.
Minimum 4 pneumatic cylinders:
- Minimum 1 double-acting cylinder with double rod.
- Minimum 2 double-acting cylinders with single rod.
- Minimum 1 single-acting cylinder.
Minimum 2 pressure gauges.
Minimum 3 3/2-way roller lever valves, normally closed.
Minimum 3 3/2-way roller lever valves with idle return.
Minimum 1 3/2-way single solenoid valve.
Minimum 1 3/2-way selector switch valve.
Minimum 2 5/2-way selector switch valves.
Minimum 1 5/2-way single pilot valve.
Minimum 1 5/2-way double pilot valve.
Minimum 2 5/2-way single solenoid valves.
Minimum 2 5/2-way double solenoid valves.
Minimum 1 shuttle valve.
Minimum 1 dual-pressure valve.
Minimum 2 one-way flow control valves.
Pneumatic distribution line.
Minimum 4 relay modules with 4 mm socket input.
Minimum 4 switch modules with 4 mm socket input.
GND and 24 V power line with 4 mm socket input.
Minimum 2 lamp modules with 4 mm socket input.
Pressure regulator with pressure gauge.
All necessary fittings and plumbing.
