Micro Wind Power Plant

A micro wind power plant is an electrical power station using wind energy to produce electricity on a small scale. This electricity can be used to supply isolated sites or fed back to a public distribution network. Learning Objectives: Analysis and study of industrial components (generator, geared motor, inverter, converter, variable speed drive, etc. Learn about Micro Wind Power Plant manufacturers for optimal educational outcomes.. ). Study of component chain efficiency. Learn about Micro Wind Power Plant India for optimal educational outcomes.. Energy balance. Measurement of voltages and currents at various circuit points. Learn about Micro Wind Power Plant exporters for optimal educational outcomes.. Demonstration of electrical laws. Information (curves, synoptic, time-based curve) continuously visible on a touchscreen. Learn about Micro Wind Power Plant equipment for optimal educational outcomes..

Its operating principle consists of converting the kinetic energy of the wind into electrical energy using a permanent magnet alternator. The electrical power produced depends on wind speed, which is simulated on the bench by an electric motor.

One permanent magnet alternator (neodymium/iron/boron) specific to wind applications, capable of producing 500 W at 1200 rpm.
One geared motor with 1.1 kW, 400 V electric motor, speed 150–1500 rpm.
One stainless steel tube frame mounted on castors, two of which are braked.
One IP66 electrical cabinet containing the electronic components: a frequency variable speed drive for geared motor speed adjustment (programmable); a rotational speed display; a battery rectifier/charger with integrated parameter display; an inverter 24 V / 230 V; a network analyser; three 60 W load lamps; three measurement points accessible on the front panel (voltage and current after the generator; voltage and current after the rectifier; voltage and current after the inverter); two 12 V 24 Ah AGM batteries; a 9.7″ touchscreen displaying operating parameters; differential circuit breakers and fuses; start/stop button; emergency stop button; one user outlet; one USB port.
