Movement and Sound Detection Application

The Movement and Sound Detection Application, is an application designed to understand the operation of the most common intrusion detector.

ATENG 11074 — Movement and Sound Detection Application

• The application “ATENG 11074” includes the following elements:
• N-ALI02. Domestic Main Power Supply Module.
• Supply voltage (single-phase): 230 VAC, 1PH + N.
  ON / OFF removable key.
• Output voltage connections:
• Two single-phase: 230 VAC.
  N-ALI02
  Single-shase supply hose connecting plug.
• Differential magnetothermal, 2 poles, 25 A, 30 mA AC, 6 KA.
  Emergency stop push-button.
• N-INT15. Two Switches with Light Module.
  Two one pole switches with light.
• Fuse: 10 A. N-INT15
• Voltage supply: 230 VAC.
  Domestic use.
• N-LAM08. Two Lamp-holders + Incandescent Lamps Module.
• Nominal voltage: 230 VAC.
• Nominal power: 2 x 40 W.
  N-LAM08
• Mains inputs/outputs: 4 mm safety sockets.
• N-INT31. Intrusion Detector from 40 to 300 W Module.
• Voltage supply: 230 VAC.
  Magnet for the mobile part of the window/door.
  Sensor for the fixed part of the window/door.
  N-INT31
• N-LAM10. Two Halogen Lamps Module.
• Two halogen lamps:
• Nominal voltage: 12 VAC.
  20 W each one.
• Terminals:
  Two terminals (PH + N) each lamp. N-LAM10
• Nominal voltage: 230 VAC.
• N-PUL22. Two Push-buttons with Light Module.
  Two light push-buttons.
• Fuse: 10 A.
• Voltage supply: 230 VAC.
  N-PUL22
• N-TIM05. Bell + Buzzer Module.
• Voltage supply: 230 VAC.
• Bell sound: 70 dB.
• Buzzer sound: 80 Db.
• All necessary cables to realize the practical exercises are included. N-TIM05
  Cables and accessories, for normal operation.
