Pitot Static Maintenance Trainer

The Pitot-Static System Trainer is designed to conduct pitot-static system checks for analog flight instrument operations. The pitot-static lines and fittings installation trainer provides hands-on training for students in inspection, removal, and installation procedures for a pitot-static instrument system.

An airspeed indicator, an altimeter, and a vertical speed indicator, along with a pitot tube and two static ports, are installed on the trainer panel.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Components :

• Altimeter.
• Vertical Speed Indicator.
• Airspeed Indicator.
• Vacuum Pump.
• Pressure Pump.
• Vacuum Control Switch.
• Pressure Control Switch.
• Pitot Adjust Knob.
• Static Adjust Knob.
• Pitot-Static System.
• Pitot Tube.
• Simulated Fuselage Static Port.
• Simulated Alternate Static Port.
• Simulated Static Source Selector Switch.
• Two Test Ports for Pitot-Static Test Set.
• Cross-Feed Knob.
• Pitot Vent Knob.
• Static Vent Knob.
• Pitot Pressure Outlet.
• Static Pressure Outlet.
• Hose.
• Fittings.
• Cables.

Documentation :

• User’s Manual.
• Study Guide.
• Instructor’s Guide.
• Training video for instructors.

Power Specs :

• Electrical Box.
• Residual Current Device.
• Emergency Button.
• Energy Signal Lamp.
• 110 VAC, 60 Hz or 220–240 VAC, 50 Hz.
